1U 17" Dual Slide Rackmount Monitor Keyboard Drawer with combo USB and PS2 Interface Touchpad


#RKD-DS-17
$1500.00 $1299.00


Description :

This RKD-DS-17, 1U 17" Dual Slide Rack mount Keyboard Monitor is a combination of Keyboard, Video and touchpad Mouse in a 1U Drawer. This dual slide Rack Monitor unit is housed on two separate siding rails which enable the Keyboard/mouse and monitor to slide independent of each other. This RKD-DS-17 unit is most commonly used where you continuously need to monitor data even when the keyboard is not being used. 1U 17" Dual slide Rack mount Monitor Keyboard unit has combo USB and PS2 interface for ease of use.




Product Features



  • 1U Dual slide rack monitor unit housed on two separate siding rails
  • Combo USB and PS2 input interface with KVM cable
  • Multiple Keyboard language selections with touchpad
  • Enhanced aesthetics with new molded front panel and two point lock
  • Continuous monitoring through closed server rack glass doors




Specifications

LCD
17" Samsung LCD
Environmental
Operation
0° to 50°C Degree
Storage
-5° to 60 °C Degree
Relative Humidity
5~90%, non-condensing
Shock
10G acceleration (11ms duration)
Vibration
5~500Hz 1G RMS random vibration
Power Input
Auto-sensing 100 to 240VAC, 50 / 60Hz
Power Consumption
Max. 48 Watt, Standby 5 Watt
Regulation Approvals
CUL, FCC, CE
Plug & Play DDC
EDID 1.3
LCD Panel MTBF (hrs)
50,000
VGA Signal Input
Analog RGB, 0.7Vp-p
Sync. Type
Separate H/V, Composite, SOG
Brightness (cd/m²)
250
Color Support
16.7 M
Contrast Ratio (Typ.)
1000:1
Viewing Angle (H/V)
160° x 160°
Display Area (mm)
338 x 270
Tr Response Time (ms)
1.3
Max Resolution
1280 x 1024
Dimensions
Product (WXDXH)
17.4 x 25.6 x 1.73 inches
Packaging (WXDXH)
23.6 x 30.3 x 7.1 inches
Weight
Net
35 lbs
Gross
48 lbs
