1U 17" HDMI, DVI and VGA 1080p Rackmount Monitor Keyboard Drawer with combo USB and PS2 Trackball

( 97 Reviews )

$2100.00 $1599.00

Description :

1U 17" 1080p HDMI, DVI-D and VGA Rackmount Monitor Keyboard Drawer, WRKD-17-HDMI-TB is a combination of Keyboard, HDMI, DVI-D and VGA Video and trackball Mouse (KVM) in 1U Rack drawer. This 1920 x 1080 Rackmount LCD Keyboard comes with a combo interface Cable which supports both USB and PS2 Keyboard interface.

Item Number: #WRKD-17-HDMI-TB

Add to Cart

Description
Reviews (2)

Product Features

1U 17" Widescreen LCD console drawer with HDMI, DVI-D and VGA
Mac and Sun Keyboard options available with hot Key support
Support full HD with 1080p resolution
Short depth design 530 mm (20.87 Inches) deep
104-Key Keyboard with either touchpad or trackball
New enhanced aesthetics with molded front handle
HDMI with speakers
3G / HD / SD-SDI Broadcast-grade input (Optional)
S-Video + Composite ( BNC ) & Audio input (Optional)
48V, 24V or 12VDC input (Optional)
MIL-Type or lockable connector (Optional)

Specifications

LCD Panel
Size (diagonal)	17.1" TFT
Max resolution	1920 x 1080
Brightness (cd/m2)	400
Backlight	LED
Colors	16.7 Million, 8-bit
Contrast ratio (typ)	600 : 1
Viewing angle (H/V)	160° x 140°
Active area (mm)	382 x 215
MTBF (hrs)	50,000
Signal input	VGA, DVI-D, HDMI w/speakers
Environmental
Operating	0 to 50°C Degree
Storage	-5 to 60°C Degree
Relative humidity	5~90%, Non-condensing
Shock	10G Acceleration ( 11 ms duration )
Vibration	5~500Hz 1G RMS Random Vibration
Casing Color	Black ( RAL 9005 )
Power
Input	Auto-Sensing 100 to 240VAC, 50 / 60Hz
Consumption	Max. 48 Watt, Standby 5 Watt
Dimensions
Product	17.4 x 20.9 x 1.73 inch
Packing	23.4 x 33.9 x 5.5 inch
Weight
Net	24 lbs
Certifications	CE, FCC, RoHS
