6U 17" WideScreen 1080p High Resolution 1920 x 1080 Rackmount LCD Monitor with HDMI, VGA, DVI and Audio Connectors

( 114 Reviews )

$1500.00 $1299.00

Description :

KVMSwitchTech's 6U 17" 1080p High Resolution Rackmount LCD, RKMTL-7U-17-HDCSV TFT unit provides users with a variety of choices such as wall Mounting or Rack Mounting. These rack mount monitor units come with Industrial Grade Samsung LCD which provides users with crisp and clear image. These RKMTL-7U-17-HDCSV, LCDs are a cost effective solution and save you valuable Rack space. Rack LCD units support simple plug and play functionality.

Add to Cart

Product Features

6U Rackmount 17" Widescreen LCD
1920 x 1080 Native Ultra high resolution
Support full HD with 1080p resolution
Green LED-backlit panel technology
1.07 Billion true colors, 10-bit
Built-in HDMI / Display-Port / VGA / Audio In/Out with Speakers
2-Year Standard Warranty (Upgradable up to 5 years )
3G / HD / SD-SDI Broadcast-grade input (Optional)
17" Touch Screen : Capacitive, Resistive (Optional)
48V, 24V or 12VDC input (Optional)
MIL-Type or lockable connector (Optional)

Specifications

LCD Panel
Size (diagonal)	17.3" TFT
Max Resolution	1920 x 1080
Brightness (cd/m2)	300
Backlight	LED
Colors	16.7 Billion, 8-bit
Contrast Ratio (typ)	1000 : 1
Viewing Angle (H/V)	160° x 140°
Display Area (mm)	381.888H x 214.812V
MTBF (hrs)	15,000
Signal Input	HDMI / DVI / VGA / Audio in and out w Speakers
Environmental
Operating	0 to 55°C Degree
Storage	-20 to 60°C Degree
Relative humidity	5~90%, Non-condensing
Shock	10G Acceleration ( 11 ms duration )
Vibration	10~300Hz .5G RMS Random Vibration
Casing Color	Black front panel ( RAL 9005 ) Dark grey rear case ( RAL 7037 )
Power
Input	Auto-Sensing 100 to 240VAC, 50 / 60Hz
Consumption	Max. 48 Watt, Standby 5 Watt
Dimensions
Product	480 x 58 x 266 mm / 18.9 x 1.9 x 10.5 inch
Packing	529 x 124 x 451 mm / 20.8 x 4.9 x 17.8 inch
Weight
Net	6 kgs / 13.2 lbs
Certifications	CE, FCC, RoHS2 and Reach Compliant

View User Manual
