8-Button Programmable Illuminated IP Wall Plate Control Keypad

( 62 Reviews )

#ANI-8WP

$299.00 $226.13

Description :

The ANI-8WP, 8 Button Wall-Plate Control System is a fantastic and useful design for system installers and smart home users. With (8) direct macro command buttons, plus an additional (8) macro commands in the WebGUI, this unit has up to (16) commands that can be executed with one push of a button for a total of 128 command capacity inside this box. Soft and colorful LED design makes for a professional presentation and the PoE (Power over Ethernet) function allows for a flexible installation without the need for an external power supply. Further, this units relay output and scheduling functions can be used to raise and lower projection screens, control matrix switchers or any device that supports Telnet. ANI-8WP has a 3 year warranty.

Add to Cart

Product Features

8) Macro buttons + (8) extra Macro programmable commands via WebGUI for up to 128 commands
(1) Relay Output for additional device control
Scheduling control for date/time specific events
Supports Key Pad, Telnet and WebGUI control
PoE or external DC power supply
US (1) Gang wall plate design with adjustable LED intensity
(56) Button Labels included (28 Pre-Printed & 28 Blank)

Specifications

Input Ports	(8) Buttons
Output Ports	(1) Relay (Terminal Block) 24V 10A, 100mOhms@1A 6VDC (1) IP Control (RJ-45)
Power Supply	5V/2.6A DC (US/EU standards, CE/FCC/UL certified)
ESD Protection: Human Body Model	±8kV (air-gap discharge) ±4kV (contact discharge)
Dimensions (WxDxH)	1.8 x 1.5 x 4 in (46x35.5x103.5mm) / Jack Excluded
Weight	0.2 lb (Unit only) / 1.1 lb (Net)
Chassis Material	Metal
Color	White
Operating Temperature	32°F~104°F (0°C~40°C)
Storage Temperature	−4°F~140°F (−20°C~60°C)
Relative Humidity	20~90% RH (non-condensing)
Power Consumption	3.3W

View User Manual
