AdderLink X-USBPRO-MS2 - Dual Head VGA, Audio and 4-port USB hub (full speed) extender to 300 meters over two CATx cables.

( 122 Reviews )

$1495.00 $1345.50

Description :

X-USBPRO-MS2-US, Adder's next generation USB, video and audio extender delivers sharp, bright and high resolution video images and high quality audio for multi screen desktops at distances up to 300m (1000ft) over CATx cables.
The AdderLink X-USBPRO-MS2-US has been designed to provide industry leading video clarity, compatibility and high rack densities.

Dual User Configuration

Two X-USB PRO units can be linked to a single computer so two users can access the system. When using two sets of X-USB PRO modules to allow two users to access a single computer the arbitration between the users is handled by the USB sub-system of the computer. This means that both users can control the computer at exactly the same time and the resulting keyboard and mouse influences will be an amalgam of the two inputs.

Local Feed Through Port

A local feed through port is provided for audio and video so a local console can be used.

Add to Cart

Description
Reviews (3)

Product Features

Specifications

Video Resolution	Video resolution up to1920x 1200at 60Hz
Skew Compensation	62ns de-skew with 2ns resolution (1/4 pixel at 1600x1200)
Extension Distance	200 meters using CAT5 Trunk cable 250 meters using CAT5e Trunk cable 300 meters using CAT6 Trunk cable 300 meters using CAT7 Trunk cable 200 meters using CAT7a Patch cable
Audio (end to end)	2 channel 16 bit Audio @ 44.1 KHz THD+N typically -80dB at 1kHz SNR typically 85dB at 1kHz
O/S Compatability	Operating system independent
Connectors (local / remote)	Local: 4 x 15 Pin D Type VGA, 1 x USB B, power jack, 2 x 3.5 mm jack socket and 2 x RJ45 Remote: 2 x 15 Pin D Type VGA, 4 x USB A, power jack, 3.5mm jack socket and 2 x RJ45
Physical Design	Local: All metal case, 122mm / 4.7’’ (w) x 75mm / 3’’(d) x 48mm / 2’’ (h) 500g / 1.1 lb. Remote: All metal case, 162mm / 6.4’’ (w) x 75mm / 3’’(d) x 48mm / 2’’ (h) 650g / 1.4 lb.
Power	100 - 240VAC, 50/60Hz input – 5V, -12W output for bth local and remote
Operating Temperature	0ºC to 40º / 32ºF to 104ºF
Approvals	CE, FCC
Optional Accessories	PSU-IEC-5VDC-2.5A: Power adapter and country- specific power lead for local module (if USB powering not possible); X-RMK-FASCIA-DUAL: Rack mount plate for X-USBPRO-MS2 module (useable for the local or remote modules); X-RMK-CHASSIS: Rack mount chassis
