Hardware compatibility
|
All computers with DVI-D, USB, Audio, RS232 - requirement dependent.
|
DVI-D - Digital Visual Interface (digital only)
|
The system supports a Single Link DVI-D resolution to a maximum of 1920 x 1200 @ 60Hz.
|
USB 2.0 with class control
|
Supports USB2.0 devices (low, full and high speed). Security feature allows the blocking of non HID devices. Isochronous devices are not supported (e.g. USB audio or video devices).
|
Digital stereo audio
|
The system transfers analog stereo audio (Line In/Line Out) via digital signalling between any transmitter/receiver pair. Additionally, the audio output of any transmitter can be multicast to many receivers.
|
RS232
|
RS232 can be passed between the units to a maximum baud rate of 115,200. RS232 is a point to point connection technology and cannot be multicast.
|
Software compatibility
|
All known operating systems.
|
Computer connections transmitter (TX)
|
1 x DVI-D, audio 3.5mm in, audio 3.5mm out, USB type B, RS232 9-pin D-type. 1 x 8p8c and 1 x SFP for AdderLink Infinity network connections.
|
Peripheral connections receiver (RX)
|
1 x DVI-D, audio 3.5mm in, audio 3.5mm out, 4 x USB type A, RS232 9-pin D-type. 1 x 8p8c and 1 x SFP for AdderLink Infinity network connections.
|
Physical design
|
1U compact case, robust metal construction. 198mm/7.92” (w), 44mm/1.76” (h), 150mm/6.0” (d), 1.1kg/2.7lbs.
|
Power
|
2.5mm DC jack (power adapter included),100-240VAC 50/60Hz, 0.8A, input to power adapter. 5VDC 20W output from power adapter.
|
Operating temperature
|
0 to 40ºC / 32 to 104ºF.
|
Approvals
|
CE, FCC.
|
