DVI-AFO-EXT-EMI DVI Fiber Optic Extender with EMI Shielding Single Link upto 3300ft


#DVI-AFO-EXT-EMI
$1500.00 $999.00

Description :

DVI-AFO-EXT-EMI SmartVM's DVI Fiber Optic Extender with EMI shielding Single Link allows to extend digital flat panel display up to 3300 feet away from your computer by TMDS digital signal transmission. This extender consists of a transmitter and receiver unit. The transmitter unit connects to your computer and receiver unit connects to your monitor. SmartVM's DVI-AFO-EXT-EMI delivers crystal clear digital images with no loss of signal. DVI Fiber Optical Extender Single link is an ideal solution for a wide range of applications like digital signage and remote monitoring on large digital displays. This type of fiber optic extender is mostly used for home theaters, medical industry, auditoriums, aerospace, military and conference rooms applications to name a few.

CUSTOM LENGTH FIBER CABLES AVAILABLE (CALL (216) 798-7530 FOR DETAILS)


Product Features



  • High Speed and long distance transmission over SC type Multi-mode single fiber
  • Corresponding to T.M.D.S signal(DVI-D Single Link)
  • RGB Clock signal is transmitted over single multi mode optical fiber
  • Self detecting function for EDID information
  • Compact Size and Easy installation


Specifications

Frequency Bandwidth
1.65Gbps (Single Link)

Supporting Graphic Resolution & Distance

WUXGA resolution (1920 x 1200) 300M (984Ft)
UXGA resolution (1600 x 1200) 500M (1,650Ft)
SXGA resolution (1280 x 1024) 700M (2,300Ft)


Using Connector
DVI 24pin Plug and SC type connector

Power Consumption
Tx
1.0W (Max)
Rx
1.0W (Max)
Optical
Optical Source
850nm VCSEL
O / E Converter
PIN Photo Diode
Using Fiber
50 / 125 LC type Multi-mode Fiber
Environmental
Operating / Storage Temperature
0 to 50 / -20 to 70 degrees Centigrade
Agency Approvals
FCC, CE , RoHs
