DVI Extender with EMI Shielding over Single Multimode Fiber Optic Cable up to 3280FT

( 84 Reviews )

$1200.00 $999.00

Description :

KVMSwitchTech's DVI-1STRSD, DVI Fiber Optic Extender with EMI Shielding over single multimode Fiber Cable enables users to extend their DVI digital flat panel display 3280 ft away from the DVI source. This DVI over Fiber extender, DVI-1STRSD uses TMDS digital signal transmission. DVI Fiber extension kit includes transmitter and receiver. The transmitter unit connects to the DVI source and receiver connects to the DVI display.

CUSTOM LENGTH FIBER CABLES AVAILABLE (CALL FOR DETAILS)

Add to Cart

Description
Reviews (3)

Product Features

High Speed and long distance transmission via SC type Multi-mode single fiber
Corresponding to TMDS signal(DVI-D Single Link)
RGB Clock signal is transmitted over single multi mode optical fiber
Self detecting function for EDID information
EMI shielded unit

Specifications

Frequency Bandwidth	1.65Gbps (Single Link)
Supporting Graphic Resolution & Distance	WUXGA resolution (1920 x 1200) 300M (984Ft) UXGA resolution (1600 x 1200) 500M (1,650Ft) SXGA resolution (1280 x 1024) 700M (2,300Ft)
Using Connector	DVI 24 Pin Plug and SC type connector
Power Consumption
Tx	1.0W (Max)
Rx	1.0W (Max)
Optical
Optical Source	850nm VCSEL
O / E Converter	PIN Photo Diode
Using Fiber	50 / 125 LC type Multi-mode Fiber
Environmental
Operating Temp/Storage Temp	0 to 50 and -20 to 70 degrees
Agency Approvals	CE, FCC, RoHS
