- Supports Mac, PC, Linux and Sun Mac OS, Sun OS, Unix
- Supports High Resolution 1920x1200 60Hz WUXGA
- Uses universal DVI Single Link connectors
- Zero pixel loss with TMDS signal correction
- Supports all USB 2.0 Devices
- Control Sun, Mac or PC computers from a common KVM console
- Compatible with all major software including Windows, Linux,Mac OS, Sun OS, Unix
- Rack mountable in a standard 19 inch rack
- Flash upgradeable firmware
- Front panel keys-used for selecting users and channels manually
- Supports USB keyboard and mouse
- Balanced stereo audio output
- Front panel tactile switch with LCD display for local control
- Full IR and RS-232 control for remote control
- Optional TCP/IP control
- Hot-key commands can be used for quick channel selection.
- Independent (asynchronous) switching of KVM and peripheral USB/audio ports. This means that you can listen to audio from one computer while working on the other OR scan a document and save in another computer.
- Complete keyboard emulation for error free booting
- Superior Video quality - 1920 x 1200 @ 60 Hz
Specifications
| Video |
|
Format
|
DVI-D Single Line
|
|
Maximum Pixel Clock
|
165 MHz
|
|
Input Interface
|
(16) DVI-D 29-pin female
|
|
Output Interface
|
(1) DVI-D 29-pin female
|
|
Resolution
|
Up to 1920 x 1200 @60Hz
|
|
DDC
|
5 volts p-p (TTL)
|
|
Input Equalization
|
Automatic
|
|
Input Cable Length
|
Up to 20 ft.
|
|
Output Cable Length
|
Up to 20 ft.
|
|
Audio
|
|
Data Rate
|
1.65 Gbps per color
|
|
Input Interface
|
(16) 3.5mm Stereo Audio
|
|
Output Interface
|
(1) 3.5mm Stereo Audio
|
|
Impedance
|
600 ohm
|
|
Frequency Response
|
20 Hz to 20 KHz
|
|
Nominal Level
|
0-1.0V
|
|
Common Mode
|
Rejection at 60dB
|
|
USB
|
|
Signal Type
|
USB 2.0, 1.1 and 1.0w/Internal Hub
|
|
Input Interface
|
(16) USB Type B
|
|
Output Interface
|
(2) USB 2.0 Type A Transparent
|
|
Control
|
|
Front Panel
|
Tactile Switch, Display: LCD 2 x 20 Character
|
|
RS232
|
Via Software @ 9600 bps
|
|
IR
|
Via Remote Control with IR-EYE Type 3
|
|
Other
|
|
Power
|
External 100-240 VAC/5VDC4A @20W
|
|
Dimensions
|
17"W x 3.5"H x 6.75"D
|
|
Weight
|
10 lbs.
|
|
Approvals
|
UL, CE, ROHS Compliant
|
|
Operating Temp.
|
32-131°F (0-55 °C)
|
|
Storage Temp.
|
-4-185 °F (-20-85 °C)
|
|
Humidity
|
Up to 95%
|
|
Emulation
|
Keyboard or Mouse
|
|
