DVS8PS SmartAVI 8 Port DVI Splitter

( 35 Reviews )

#DVS8PS

$699.00 $540.00

Description :

The SmartAVI DVS8PS is a 8 Port DVI Splitter which enables users to connect eight DVI-D enabled displays or projectors. It offers excellent image quality, as if each of the monitors were directly connected to the source.

Add to Cart

Product Features

Onboard DDC Learning and emulation
Can learn any type of DDC
Supports DVI-D Single link input
Supports DVI-D Single link Output
Resolution up to maximum 1920 x1200 @ 60 Hz
Perfect picture quality

Specifications

Video
Input	1 DVI-D Female
Output	8 DVI-D Female
Amplifier Bandwidth	1.65 Gbps
Input Video Signal	1.2 volts p-p
Max. Resolution	1920 x 1200 60 Hz
Power Adapter (min)	AC 100V~240V/50~60Hz
Cable Distance to Monitor	10 m (max)
Input DDC Signal	5 volts p-p (TTL)
Single Link Range	1920 x 1200
Signal Type	Standard DVI Signal
Housing	Metal
Weight	5.5 lbs

View User Manual
