Shinybow SB-5645LCM 4x4 HDMI Matrix Routing Switcher w/ Full EDID Management/Learning

( 85 Reviews )

$900.00 $695.00

Description :

The Shinybow SB-5645LCM is a high-performance 4x4 matrix routing switcher for HDMI signals. This switcher supports data rates up to 6.75 Gbps, enabling 1080p HDMI formats and UXGA/WUXGA/DVI resolution to any HD display. High Definition Digital signals can be selected and distributed to any (4) outputs simultaneously. The switcher is certified as being fully HDMI and HDCP compliant, with RoHS, CE, FCC certifications. Supports high resolution HDMI sources routed to HDMI displays, monitors, projector or audio receivers. The EDID can be selected between (7) different modes. Control is provided via front panel push buttons, IR remote or via RS-232. A RS-232 Windows GUI interface is provided for matrix routing.

The SB-5645LCM is our next-generation 4x4 HDMI matrix routing switch, designed for multiple sources and displays. There are (4) HDMI connections for inputs and (4) HDMI connections for outputs located on the back panel. This unit has EDID management and EDID memory, including a new feature called “Fast Speed Start®” which permits switching between HDMI sources in as little as 2 seconds. The SB-5645LCM supports bandwidth of 6.75Gbps and data rates up to 2.5 Gbps, enabling 1080p HDMI formats and UXGA DVI resolutions.

Building upon our successful 5645p series, the SB-5645LCM’s front panel includes an LCD display with (2) data display lines. Functional manual control is achieved through push buttons located on the front panel. External functional control is achieved through a RS-232 connection or through the IR remote control. The RS-232 connection allows functions to be controlled by systems like Control4 (drivers included) or any computerized software/hardware control system.

When using the SB-5645LCM matrix routing switch, one-to-many or many-to-one connections can be established. You can easily connect any input device to any output device. You can also establish a single input device to many output devices, eliminating the need to constantly re-route video input and output cables.

Add to Cart

Product Features

(4) HDMI digital source devices matrix switched to (4) HDMI devices
HDMI digital video w/ embedded audio, DVI format and CEC/HDCP 2.0 compliant
(7) function keys control and worldwide EDID modes for HDTV resolutions
Link speeds of up to 6.75 Gbps (link clock rate of 225Mb Hz). Support HDMI 1.4a 3D formats
Wide range of HD resolutions from PC XGA to WUXGA 1920x1200 and HDTV/DTV resolutions 480i/480p, 576i/576p, 720p, 1080i & 1080p
Compatible with all HDMI source devices, PC monitors, Plasma HD display, HDTV and audio receivers/amplifiers
Digital video TMDS formats for resolutions up to 1080p-60 with Deep color 36-bit
Digital Audio Support : Dolby TrueHD, Dolby Digital, Dolby Digital Plug/ex, DTS, DTS-HD, DTS-HD Master, DTS-EX, PCM, PCM2, LPCM2
Various User Interface control:
- Windows based GUI control via RS-232 port
- Front panel push button
- IR wireless remote control
- Third party RS-232 controller (via simple ASCII)
Supports World Wide Control Functions: ALL/OFF/RECALL/ENTER/MEMORY/EDID/LOCK
Supports EDID Modes:
- Internal Modes: AUTO/1080p-2CH/1080p-5.1/1080p-7.1/1080i-2CH/720p-2CH
- External Modes: Passing mode
Automatic scanning input & output status via LED show on front panel
Supports IR remote and IR extender with distances up to ~1000 ft (300M) Maximum
EDID configuration via internal modes
Consumer Electronic Control (CEC) switch all open or OFF

Specifications

Type of Switcher	(4) HDMI Inputs to (4) HDMI Outputs Matrix Switcher
HDMI Support	HD 1080p-@60Hz, H36-bit Deep color, 3D (1.4a) formats
HDCP / CEC Support	HDCP 2.0 Compliant, CEC Compliant
Video Bandwidth	Double Data Rates: 225Mhz, Total 6.75Gbps bandwidth
Digital Video Support	Full HD Resolution: 480i / 480p / 720p / 1080i / 1080p
Digital Audio Support	Multi Audio Formats 5.1 / 7.1, MAT(MLP), Dolby Digital, Dolby TrueHD, Dolby Digital Plus, DTS, DTS-ES 6.1, DTS-HD, DTS-HD-HRA, DTS-HD Master, (PCM-2CH)
Controls	IR remote controller IR external port x1 (OD 3.5mm ear phone jack) Select & Function buttons on front panel RS-232 series interface
Source Status	Automatically scans source Inputs via LED
Function Control Key	ALL / OFF / RECALL / ENTER / MEMORY / LOCK / EDID
Infrared Frequency	38Khz
IR External Distance	~1000 feet / 300M maximum
HDMI I/O Connector	HDMI Type A - SMD 19pin female type
Temperature	32°F - 100°F Operation (0°C - 38°C)
Dimensions (LxWxH)	19 x 9.85 x 1.75 in (482x250x44mm)
Rack Mount	1RU High 19in rack mount (with rack mount)
Power Supply	DC12V / 3A, Universal world wide type 50/60Hz, 100~230 VAC
Power Consumption	2150 mA Maximum
Safety Approvals	CE, FCC, RoHS (2002/95/EC)
Product Weight	1.85 Kgs / 3.08 lb

View User Manual
