Shinybow SB-5430 4x2 S-video + Audio/Video Switcher w/IR Remote

( 63 Reviews )

#SB-5430

$299.00 $198.00

Description :

This Shinybow SB-5430, 4 in 2 out Composite/ S-Video/Audio Video Selector works as a switcher for multiple Audio/Video sources and displays. It is capable of switching Composite, S-Video and Stereo Audio signals between four sources and two displays (same signal on both outputs) with compatible inputs. It supports a maximum bandwidth of 100MHz with sharp and highly defined video for multiple resolutions of up to 480i 576i. Being a Matrix Switcher, it allows any input to be routed to any output, or same input to be routed to all outputs. This Video Matrix eliminates the need to constantly move around video input and output cables. The 4x2 Routing Switcher works with all Audio/Video equipment that has proper connections: such as Cable and Satellite receivers, Computers, Video Scalers, DVD players, VCR's, etc.

Add to Cart

Description
Reviews (3)

Product Features

4 Inputs:Composite/S-Video/Audio (RCA)
2 Outputs:Composite/S-Video/Audio (RCA)
IR and Manu double select
Video Bandwidth 100Mhz
Video Distortion 1.2db
Audio Distortion 0.6db
Channel Isolation 50db
S/N Ratio > 50db
Use IR Remote Controller (Frequency 38KHz).
Lower Power Consumed 12VDC,@300~500mA.

Specifications

Video Input:	4 x Composite 0.5-2 Vpp, 75 Ohms,RCA Socket. 4 x S-Video (Y/C) 75 Ohms, Mini-Din 4P Socket
Audio Input	8 x Stereo Audio: L+R 5Vpp, 47k Ohms. RCA socket
Video output	2 x Composite 1 Vpp, 75 Ohms,RCA Socket. 2 x S-Video (Y/C) 75 Ohms, Mini-Din 4P Socket.
Audio Output	4 x Stereo Audio: L+R 5Vpp, 47k Ohms. RCA socket
Video Bandwidth	30Mhz, Maximum 100MHz. +/- 3db
Video Distortion	<1.2db
Audio Distortion	<0.6db
Channel Isolation	>50db
Signal to Noise Ratio	>50db
Power Consumption	+12V DC @ 300mA or 500mA.
Power Source	AC to DC Adapter
