Shinybow SB-4184LCM 8x4 VGA w/ Stereo Audio Matrix Routing Switcher

( 67 Reviews )

$1200.00 $895.00

Description :

The SB-4184LCM is a true 8x4 matrix routing switcher for VGA-AUDIO signals. It has (8) individual VGA inputs with (4) individual VGA-AUDIO outputs. Because it is a matrix router, any input may be routed to any output; or the same input may be routed to all outputs or any combination. It completely eliminates the need to constantly move around VGA input and output cables. The SB-4184LCM is useful for matrix signals from VGA-AUDIO source devices (such as VGA based: Personal computers, Satellite Receivers, CAT5 Set Top Boxes, etc.) to VGA destination devices (such as VGA based: HDTV, LCD TVs, Plasma TV Sets, Video Projectors, etc.). Selection of inputs can be made via the front panel push buttons or an infrared remote control or RS-232 control by a computer.

Add to Cart

Description
Reviews (2)

Product Features

Supports (8) VGA-Audio Inputs to (4) VGA-Audio Outputs Matrix Switcher
Supports (8) VGA-Stereo Audio Input signal sources
Supports (4) VGA-Stereo Audio Output Signal devices
Higher video bandwidth 450MB each path R,G,B signals
Supports HD high definition resolutions XGA, SXGA, UXGA, WSXGA, WUXGA
Compatible with all VGA video monitor devices, Plasma displays and Projectors
Supports RS-232 serial interface protocol command list
Control via a PC RS-232 drive compatible with Win-95/98/2000/XP
Various User Interface Controls:
- Attached Window based control software for Desktop or NB control by RS-232 port
- Manual control via the front panel button
- IR remote control
- IR extension control
Supports desktop with ear mounts and 19 inch 1U rack mountable type panel
Power supply DC12 Volt, Universal Type Switch 100~230VAC, 50/60Hz

Specifications

Type of Splitter	(8) In to (4) Out, VGA (RGBHV)-Stereo Audio Matrix Switcher
Input Ports: Group	(8) VGA (RGBHV) via HD-15p VGA connector (8) Stereo Audio via HD-15p VGA connector
Output Ports: Group	(4) VGA (RGBHV) via RCA connector (4) Stereo Audio via RCA connector
Video Bandwidth	450MHz (-3dB), 200mVpp
Video Supported	Higher resolution formats HD 1920x1200 (WUXGA)
Low All Hostile Crosstalk	83dB@5MHz
Controls	IR remote, Select buttons on the front panel & RS-232
PC RS-232 Control	RS-232 interface serial via DRV on a PC
Gain Control	60MHz 0.1dB gain flatness
Chassis Material	Metal
Dimensions (WxDxH)	17.5 x 8.25 x 1.75 in
Weight	6.2 lb (Unit only) / 8.8 lb (Net)
Safety Approvals	CE, FCC, VCCl, Erp, WEEE
Power Supply	DC12V / 2A (consumption 1.2A Max) Uses Universal Switch Type 50/60Hz,100~230VAC
