Shinybow SB-5544LCM 4x4 Composite Video/Stereo Audio Matrix Switcher


$799.00 $630.00


Description :

The SB-5544 LCM is a true matrix routing switcher for AV (Composite & Stereo Audio) signals with full support of NTSC or PAL Composite Video & Stereo Audio systems. It has (4) individual Composite Video and Stereo Audio inputs with (4) individual Composite Video and Stereo Audio outputs. Because it is a matrix router, any input may be routed to any output; or the same input may be routed to all outputs or any combination. It completely eliminates the need to constantly move around video audio input and output cables. The SB-5544LCM is useful for matrix signals from Composite Video and Stereo Audio source devices (such as: VCRs, Camcorders, Video Game Consoles, Video CDs, DVDs, Satellite Receivers, CAT5 Set Top Boxes, etc.) to Composite Video/Audio destination devices (such as: LCD TV, HDTV, Plasma displays, Projectors, etc.). Selection of inputs can be made via the front panel push buttons or an infrared remote control or RS-232 control by computer.




Product Features



  • (4) Inputs to (4) Outputs Matrix Switcher
  • Supports Composite Video and Stereo Audio (AR/AL) signals
  • High bandwidth video 450MHz for each Composite Video port
  • Supports IR remote and external IR, front panel buttons and RS-232 serial interface protocol controls
  • Compatible NTSC or PAL TV video systems
  • Various User Interface Control:
    • Attached Window based GUI control software via control interface driver for 2000/XP/WIN7-32/WIN7-64/WIN8
    • Front panel button for manual control
    • IR remote control or external IR to control the switcher
  • Supports desktop with ear mounts and 19 inch 1U rack mountable type panel
  • Power supply uses universal switch type AC 100~240VAC, Frequency 50/60Hz


Specifications

Type of Switcher
(4) Inputs to (4) Outputs Audio-Video Matrix Switcher
I/O Signals
  • Video: Composite Video (0.5~1.0Vpp, 75Ohms-RCA (Yellow)
  • Audio: Stereo Audio (AR/AL) via (2) RCA connectors (Red/White)
Video Bandwidth
450MHz (-3dB), 200mVp-p
Audio Specification
20Hz ~ 20KHz
Source Status
Automatically scan source inputs via LED
Low All Hostile Crosstalk
-83dB@5MHz
Gain Control
60MHz -0.1 dB gain flatness
IR Frequency
38Khz
IR External Distance
SB-100 phone-jack 3.5mm 3C cable ( 1000 ft / 300M Max) / SB-100C phone-jack 3.5mm 2C cable (2M)
RS-232 Protocol Control
STD RS-232 interface serial via PC DRV
Rack Mount
Supports 1RU High 19 in rack mount pack (#1U-300L)
Safety Approvals
CE, FCC, RoHS, REACH
Dimensions (LxWxH)
12 x 6 x 1.75 in
Power Supply
DC12, 1.25A Universal Switch Type AC100~240V, 50/60Hz
Power Consumption
750mA Maximum full load
Weight
3.3 lb (Unit only) / 5.5 lb (Net)
