Shinybow SB-5688CAP 8x HDMI Inputs / 8x HDMI & 8x HDBaseT™ PoH Outputs - UHD 4K2K Matrix Switch w/ EDID Management/Learning w/ Auxiliary Audio I/O

( 148 Reviews )

$7900.00 $4327.10

Description :

The Shinybow SB-5688CAP is a professional 8x8 matrix routing switch with PoH (Power Over HDBaseT™). Supporting (8) HDMI and (8) Auxiliary Audio Inputs and (8) HDMI, (8) SPDIF and (8) HDBaseT™ (PoH) Outputs. The SB-5688CAP is based on the HDBaseT™ standards and supports full HDMI video resolution with embedded EDID and PoH function, Audio, RS-232, Ethernet and bi-directional IR, all over a single category cable. With a signal bandwidth of 340Mhz, so there is no signal degradation. High Definition Digital signals can be selected and distributed to any (8) inputs to the (16) outputs simultaneously (channel outputs mirrored). The switcher is certified as being fully CEC, ARC and HDCP 2.0 compliant, full HD 4K2K HDMI V1.4a 3D formats,with data rates up to 6.75 Gbps. Using the build-in booster, each HDMI output port is capable of driving cable lengths for 1080p up to 98 ft (30M) & 4K2K up to 66 ft (20M). Supports UXGA/WUXGA/DVI 1920x1200 resolutions to any HD display. The SB-5688CAP has 1x HDMI and Auxiliary Audio (analog stereo audio) connector per input, effectively making this an (8) in x (16) out switcher (same signal on both outputs). Using the IR remote, the switcher’s HDBaseT™ Extender Transmitter (Tx) allows you to connect a source in a remote location. Likewise, the HDBaseT™ output and our HDBaseT™ Receiver allows you to connect a display in a remote location. The EDID management can be selected between (7) different modes. Control is provided via front panel push buttons, IR remote, RS-232 or TCP/IP (not a web-browser). An RS-232 Windows GUI interface is provided for matrix routing control (Windows only).

Add to Cart

Product Features

(8) HDMI with Auxiliary Audio (Analog Audio) player devices matrix switched to (8) HDMI with S/PDIF outputs and (8) HDBaseT™ Transmitter with PoH output to (8) destinations
Application HDBaseT™ specification with PoH 48VDC, IR, RS-232, Multi Audio Format and HD
Video Signals over one CATx (6/6a/7) category cable
HDMI digital video w/ embedded HDCP, DVI format and CEC/HDCP 2.0 compliant
Worldwide control EDID modes for HDMI full 4K2K (24/30 Hz) HD video resolutions
Link speeds of up to 6.75Gbps (link clock rate of 340MbHz), Supports HDMI 4K2K, 1.4a 3D formats
Wide range of HD resolutions from PC XGA to WUXGA 1920x1200 and HDTV/DTV HDMI resolutions 480i/480p, 576i/576p, 720p, 1080i/p & 4K2K (24/30Hz)
Compatible with all HDMI source devices, PC monitors, Plasma HD displays, HDTV and audio receivers or audio amplifiers
Digital video TMDS formats resolutions up to 4K2K with Deep color 36-bit
Digital Audio Support:Dolby TrueHD, Dolby Digital, Dolby Digital Plug/ex, DTS, DTS-HD, DTS-HD Master, DTS-EX, PCM, PCM2, LPCM2
Audio Input: Supports Auxiliary Audio (analog stereo audio)
Audio Output: Support Digital Audio ARC or Digital Audio S/PDIF (from HDMI source or Auxiliary Audio)
Various User Interface controls:
- Windows based GUI control via RS-232 port
- Front panel push button
- IR wireless remote controller
- Ethernet Switch control
- Third party RS-232 controller (via simple ASCII)
Support world wide (9) control function keys:
- Full function front panel controls: ARC/AUX/ALL/OFF/EDID/LOCK/RECALL/MEMORY/ENTER
Support EDID modes:
- a. (7) Embedded EDID modes: FSS/H24-3D/H24-3D-M/H36-3D/H36-3D-M/4K2K-3D/DVI-D 1920x1200-60Hz
- b. External modes: Learning mode-1 (Single Learning) & Learning mode-2 (Multiple Learning)
Automatic scanning input & output status via LCM show on front panel
Using the build-in booster, each HDMI output port is capable of driving cable lengths for 1080p up to 98 ft (30M) & 4K2K up to 66 ft (20M)
Supports IR Remote and IR Extender with distance up to ~984 ft (300M) Maximum
Supports Universal power adaptor AC90V~AC240V, 50/60Hz

Specifications

Type of HDMI Switcher	(8)x inputs to (8)x iutputs HDMI over HDBaseT™ Matrix Switch with Audio and Extension
HDMI Support	HDMI 4K2K, 1080p-@60Hz, H36-bit Deep color, 3D of HDMI V1.4 formats
HDBaseT Support	Bi-directional IR, RS-232, Multi format Audio, Ethernet and PoH function, over one CATx cable
HDCP/CEC Support	HDCP 2.0 Compliant, CEC Compliant
Video Bandwidth	Double Data Rates: 340Mhz, Total 6.75Gbps bandwidth
Digital Video Support	HD: 480i/480p/720p/1080i/p and 4K2K up to 36bit deep color
Inputs	Video Inputs (HDMI): 8x HDMI (HDMI or DVI digital source) Audio Input: 8x Audio (Analog Stereo, AUX port. 3.5mm Jack)
Outputs	Video Outputs (HDMI): HDMI: 8x HDMI (to Destination) HDBaseT: 8x HDBaseT™ Transmitter (with PoH 48VDC via category cable & RJ-45 connector) Audio Output: 8x S/PDIF: Multi Audio Formats 5.1 from HDMI or LPCM-2CH from Auxiliary audio 8x ARC: TV Return Channel Audio 8x HDMI: Multi Audio Formats 5.1/7.1, MAT (MLP), Dolby Digital, Dolby TrueHD, Dolby Digital Plus, DTS, DTS-ES 6CH, DTS-HD, DTS-HD-HRA, DTS-HD Master, (PCM-2CH)
HDBaseT™ Control In	8x IR in (Send IR signals To 8x Rooms via HDBaseT™ Transmitter) 1x ALL IR in (Send IR Signals To 8x Rooms - via HDBaseT™ Transmitter)
HDBaseT™ Control Out	8x IR out (Link to Receive IR signals from 8x Rooms via HDBaseT™ Extender) 1x ALL IR out (Link to Receive IR signals from 8x Rooms via HDBaseT™ Extender) 1x LAN (All Switcher HDBaseT™ Transmitter Ethernets link to HDBaseT™ Receiver)
HDBaseT Control I/O	8x RS-232 I/O (Control 8x Rooms RS-232 via Switcher HDBaseT™ Extender Tx)
Switch Controls	1x Select & Function buttons on front panel (Data status via LCM panel show out) 1x IR Remote Controller (switch control) 8x IR Room Remote Controller (switch control) 1x IR External port (switch control via 3.5mm OD Jack) 1x RS-232 series interface (switch control) 1x Ethernet series interface (switch control)
Source Status	Input status LEDs indicates presence of a live signal
(25) Function Control Keys	1. ARC 2. AUX 3. ALL 4. OFF 5. RECALL 6. ENTER 7. MEMORY 8. LOCK 9. EDID 10. Destination button (1) thru (8) 11. Source button (1) thru (8)
(7) EDID management	Select Embedded EDID modes: Mode1: FSS Mode2: H24-3D Mode3: H24-3D-M Mode4: H36-3D Mode5: H36-3D-M Mode6: 4K2K-3D, PCM-2CH Mode7: DVI-D 1920x1200-60Hz Select LEARNING mode: Learning Destination EDID to Link Source. Learning mode-1 (Single Learning), Learning mode-2 (Multiple Learning)
Infrared Frequency	38Khz
IR External Distance	~984 ft/300M maximum
HDBaseT™ Extender Distance	~328 ft/100M maximum
HDMI I/O Connector	HDMI Type A-SMD 19pin Female Type
Temperature	32°F-100°F Operation (0°C-38°C)
Dimensions (LxWxH)	19 x 9.85 x 3.46 in (482x250x88 mm)
Rack Mount	2RU High 19 in Rack Mount #2U-440L (with rack mount)
Power Supply	AC 100~240VAC 50/60Hz (Power Consumption: 10A Maximum)
Safety Approvals	CE, FCC, RoHS, REACH
Product Weight	3.85 Kg/8.47 lb
Shipping Weight	10.4 Kg/23 lb
