SmartAVI StretcherPro2 STR2PS Digital Signage Display Wall Controller

( 69 Reviews )

#STR2PS

$3199.00 $2520.00

Description :

SmartAVI StretcherPro2 STR2PS is a digital signage / display wall controller that utilizes HD Multilayout technology. StretcherPro2 can take any DVI source and stretch it among four displays, In any layout you choose. The new StretcherPro2 STR2PS is capable of stretching any HD display over four screens, while maintaining any resolution up to 1920 x 1080 on each screen. This powerful new version stretches the video image in multiple ways including: Wall mode (2x2), vertical (1x4), horizontal (1 x 4), Dual horizontal (2x1), dual vertical (1x2), or clone the image (1:1).

Add to Cart

Description
Reviews (5)

Product Features

4 Screen Multilayout Digital Signage/Video Wall Controller
Supports DVI-D Input
Internal DDC Tables
Learn mode for obtaining the DDC specifications (DDC table) from a PC, Mac, or from the connected monitors
Resolutions up to 1920 x 1080
Output to 4 Screens, in Clone, Stretch Horizontal or Vertical Modes
Stand-Alone Unit, Requiring no Additional Hardware or Software
Multiple Units can be Linked for Larger Wall Configuration
DVI-D or VGA Output with Adapter

Specifications

VIDEO
Format	DVI-I Single Line
Maximum Pixel Clock	165 MHz
Input Interface	(4) DVI-D 29-pin female
Output Interface	(1) DVI-I 29-pin female support dvi-d and vga using adaptor
Resolution	DVI-I up to 1920 x 1080 @60Hz • VGA out up to 1600 x 1200 @60Hz
DDC	5 Volts p-p(TTL)
Input Equalization	Automatic
Input Cable Length	Up to 20 ft.
Output Cable Length	Up to 20 ft.
Interface (RX)	(2) USB Type A (Female)
Learn mode	Obtain the DDC specifications (DDC table) from a PC, Mac, or from the connected monitors
CONTROL
Front Panel	Tact Switch w/OSD
RS-232	RS-232 Commands
Front LCD	2x20
OTHER
Power	External 100-240 VAC/5VDC4A @ 20W
Dimensions	17”W x 1.75”H x 10.25”D
Weight	5 lbs
Approvals	UL, CE, ROHS Compliant
Operating Temp.	32-131 F (0-55C)
Humidity	Up to 95%
