X124-S801e Cyberview 1U 24" 1920 x 1200 Rackmount Monitor Keyboard with 8 Port VGA KVM Switch Touchpad

( 102 Reviews )

#X124-S801

$2700.00 $2473.00

Description :

The newest CyberView Rackmount LCD monitor X124-S801e adds larger screen real estate to your rack environment. With the choice between a left facing monitor or a right facing monitor, as well as the integrated 8 port VGA/USB KVM, the CyberView X124 series handles the critical needs in datacenters or limited space server rooms and IT closets, while providing DVI 1920x1200 high resolution support. In instances where a rack side is placed against a wall, the X124 allows the user to be positioned facing the wall comfortably rather than snugged up against it.

Add to Cart

Description
Reviews (3)

Product Features

1U 24" widescreen LCD console drawer w/ 8 Port USB VGA KVM
Support 1920 x 1200 native WUXGA Ultra High resolution
104-key keyboard with either touchpad or trackball options
New enhanced aesthetics with molded front handle
Cables must be purchased separately
Combo interface for PS/2 or USB input

Optional Configurations (Call for availability)

HDMI signal Input
SDI signal input
SUN Micro and Mac keyboard options available
PIP & Picture by Picture viewing efficiency
12, 24, 48, 110-125 V DC Power
Additional languages supported
Multiple Integrated KVM Options

Specifications

Mechanical
Height	1.73 in (44 mm)
Width	17.4 in (441.6 mm)
Depth	31.5 in (800 mm)
Form Factor	1U rackmount on slide out rails
Weight	35.4 lbs. (16.1 kg)
Environmental
Operating Temperature	32 to 122°F (0° to 50°C)
Storage Temperature	23 to 140°F (-5° to 60°C)
Relative Humidity	5-90% Non-Condensing
Shock	10G Acceleration (11 ms duration)
Vibration	5-500Hz 1G RMS random vibration
Power
Input	Auto-sensing 100 to 240VAC, 50 / 60Hz
Consumption	Screen On: 65W; PowerSave: 30W
LCD Display
Diagonal Size	24.1" Widescreen TFT
Max Resolution	1920 x 1200
Brightness (cd/m2)	300
Color Support	16.7 M
Contrast Ratio	1000:1
Viewing Angle	178° x 178°
Display Area	518 x 324 mm
Console Port	DVI-D
Compliance	FCC, CE, RoHS2, Reach
