1U 17" Ultra High Resolution 1920 x 1200 Rackmount LCD Monitor with DVI-D and VGA Connectors


#RKMTL-1U-17-UN
$2400.00 $1999.00


Description :

1U 17" Ultra High Resolution 1920x1200 Rackmount LCD, RKMTL-1U-17-UN also referred to as 1U LCD is a flip up monitor in 1U Drawer. This Rack lcd unit saves space for your Rack environment. These LCDs support simple plug and play functionality and do not require any additional software. This 1920X1200 TFT Rackmount LCD Monitor allows for viewing and monitoring of data even through closed glass doors. 1U rack mount LCD Monitor units come with an industrial grade LCD panel.




Product Features



  • 1U Rackmount 17" Widescreen LCD
  • 1920 x 1200 Native WUXGA Ultra High resolution
  • Support full HD with 1080p resolution
  • Green LED-backlit panel technology
  • 1.07 Billion true colors, 10-bit
  • Built-in DVI-D and VGA Connectors
  • HDMI / Audio / 3G / HD / SD-SDI Broadcast-grade input (Optional)
  • 17" Touchscreen : Capacitive, Resistive (Optional)
  • 48V, 24V or 12VDC input (Optional)
  • MIL-Type or lockable connector (Optional)

Specifications

LCD Panel
Size (diagonal)
17.1" TFT
Max resolution
1920 x 1200
Brightness (cd/m2)
210
Backlight
LED

Colors
1.07 Billion, 10-bit
Contrast ratio (typ)
600 : 1
Viewing Angle (H/V)
130° x 110°
Active area (mm)
367 x 230
MTBF (hrs)
20,000
Signal input
DVI-D / VGA
Environmental
Operating
0 to 50°C Degree
Storage
-5 to 60°C Degree
Relative humidity
5~90%, Non-condensing

Shock
10G Acceleration ( 11 ms duration )
Vibration
5~500Hz 1G RMS Random Vibration
Casing Color
Black front panel ( RAL 9005 )
Dark grey rear case ( RAL 7037 )
Power
Input
Auto-Sensing 100 to 240VAC, 50 / 60Hz
Consumption
Max. 48 Watt, Standby 5 Watt
Dimensions

Product
17.4 x 18.1 x 1.73 inches
Packing
 27 x 23.2 x 4.7 inches
Weight

Net
26 lbs
Certifications
CE, FCC, RoHS
