AV4PRO-DVI-QUAD-US AdderView Pro 4 Port Quad Head Dual link DVI-I with USB True Emulation Technology

( 100 Reviews )

$1899.00 $1775.00

Description :

The AV4PRO-DVI-QUAD-US, AdderView Pro 4 Port Quad Head is designed to enable four Quad Head Dual link DVI-I computers to be controlled from a single high resolution KVM console using either dual link DVI or high definition analogue video links. The switch makes use of ADDER's True Emulation technology which enables USB HID devices to be continuously emulated to each computer. This unique technology enables instantaneous and reliable hotkey switching whilst also supporting the extra keys and features of enhanced keyboards and mice. Furthermore, the ADDERView includes two independently switchable USB 2.0 channels and an audio channel, giving the user the flexibility to attach selected peripherals to different computers. Models are available supporting single, dual, triple or quad head DVI or VGA computers.

Add to Cart

Description
Reviews (2)

Product Features

Specifications

Hardware compatibility	All computers with USB interfaces
Software compatibility	Operates with all known software and operating systems including Windows (all), DOS, Linux, Unix, BSD, all Sun OS, all Mac OS, NetWare etc. Computer connections at switch: USB2.0 type B, Dual-link DVI-I (up to 4 per connection), 3.5mm stereo jack
Local KVM console connection	Video: Dual-link DVI-I (Dual x 2, Triple x 3 or Quad x 4) Resolution: All resolutions up to 5MP per head (eg 2560x1920 4.92M3-R). Keyboard/Mouse: 2 x USB type A Switched USB: 2 x USB2.0 type A Switched USB: Supports USB 2.0 devices in low, full and high speed modes. USB True Emulation: Emulates keyboard and mouse on each port. Low speed HID USB 2.0 devices supported Audio: 3.5mm stereo jack Other Connections: Options (flash upgrade, sync with other AV4PRO-DVI-MS and RS232 triggered power switches): Modular 10P10C
Physical design	2.5U high metal case 26cm (w), 15cm (d), 10cm (h)
Power	2.5mm DC jack (power adapter included), 100-240VAC 50/60Hz input to power adapter, 5VDC 2A output from power adapter
Operating temperature	0 - 40 deg C (32 to 104 deg F)
Approvals	CE, FCC
Additional accessories	DVI to VGA adaptor: VSA11 Single link DVI-D to DVI-D video cable: VSCD1 Combined dual link DVI-D and USB (USB type A to B) cable: VSCD3 (2m length); VSCD4 (5m length) Audio cable 2m (3.5mm stereo jacks): VSC22 Flash upgrade adapter plus standard 3m patch lead: VSC40 Two 19inch rackmount brackets and four screws: RMK5PROMS RC4 remote control plus standard 3m patch lead: RC4-8P8C
