HDMI Extender over two Cat5e/6 Cables upto 200ft

HDMI Extender over two Cat5e/6 Cables upto 200ft

( 48 Reviews )

#HDMI-2CATHD

$270.00 $165.00

Description :

KVMSwitchTech's HDMI-2CATHD, HDMI Extender over Cat5e/6 enables users to locate their HDMI LCD, TV or projector up to 200 feet from the HDMI source. The HDMI Extender kit includes transmitter and receiver unit. It transmits HDMI signal with HDCP compliance up to 30 meters@1080p & 60MHz, & 60 meters@1080i & 60MHz.

Add to Cart

Description
Reviews (1)

Product Features

Use CAT5e/6 Cables to achieve long distance transmission
Follows IEEE-568B standard
Transmission distance of up to 30 Meters (1080p) and 60 Meters (1080i)
Signal rates up to 2.25Gbits to support 1080p displays
Supports HDMI signals
HDCP Compliant

Specifications

Input Video Signal	0.5-1.0 volts p-p
Input DDC Signal	5 Volts p-p (TTL)
Maximum Single Link Range	1920x1200, 1080p
Output Video	HDMI 1.3
Video format supported	DTV/HDTV: 1080p/1080i/720p/576p/480p/576i/480i
Transmission distance	CAT5e/6 Cable 30M for 1080p
Transmission distance	CAT5e/6 Cable 60M for 1080i
Interlaced	(50&60Hz) 480i/576i/1080i
Progressive	(50&60Hz) 480p/576p/720p/1080p
Operating Temperature	0 to 70C
Operating Humidity	10% to 85% RH (non condensing)
Storage Temperature	-10C to 80C
Storage Humidity	5% to 95% RH (non condensing)
External Power Supply	5V DC @2A
