MRK-K17e-2L Cyberview 2U 17" Dual Display Left and Center Display Port 3840 x 2160 Rackmount Console Drawer Touchpad--


#MRK-K17e-2L
$6300.00 $5575.00


Description :

Austin Hughes Cyberview MRK-K17e-2L 2U 17" Dual Display left hinged mount High Resolution 3840 x 2160 Rackmount Monitor Keyboard Console Drawer is a combination of Keyboard, Display Port Video and touchpad Mouse (KVM) in 2U Rack drawer. This   Rackmount LCD Keyboard  comes with a combo interface cable which supports both USB and PS2 Keyboard interface. MRK-K17e-2L units are specifically designed for Command and Control Centers for side by side display applications.To ensure chassis ruggedness, mobility and quality, as well as being suitable for harsh environment applications, the MRK-K17e-2L console drawer is meticulously constructed by our team of experts in our own CNC facilities for such applications.




Product Features



  • Cyberview MRK-K17e-2L 2U 17" widescreen LCD console drawer with Display Port inputs per display
  • Rugged construction for mobility & durability
  • Fits 24" ~ 36" rack via adjustable mounting brackets
  • 4K UHD (3840 x 2160) native resolution / 1920 x 1080 & 1920 x 1200 resolution support
  • 104-key Keyboard with Touchpad
  • 2-Year standard warranty (upgradable up to 5 years)
  • HDMI with Speakers (Optional)
  • 3G / HD / SD-SDI Broadcast-grade input (Optional)
  • Front USB hub port for device access (Optional)
  • 48V, 24V or 12VDC input (Optional)
  • Sunlight Readable LCD for 17" FHD & 19” 4:3 (Optional)

Specifications

LCD Panel
Size (diagonal)
17.3" TFT
Max resolution
1920 x 1080
Brightness (cd/m2)
300
Backlight
LED

Colors
16.7 M, 8-bit
Contrast ratio (typ)
1000 : 1
Viewing angle (L/R/U/D H/V)
89/89/89/89
Display area (mm)
381.888H x 214.812V
MTBF (hrs)
50,000
Signal input
DisplayPort 1.2 / HDCP 1.3
Environmental
Operating
0 to 55°C Degree
Storage
-20 to 60°C Degree
Relative humidity
5~90%, Non-condensing

Shock
10G acceleration (11 ms duration )
Vibration
10~300Hz 0.5G RMS random vibration
Operating Altitude / Non Operating Altitude
16,000ft  / 40,000ft
Power
Input
Auto-Sensing 100 to 240VAC, 50 / 60Hz
Consumption
Max. 38 Watt, Standby 5 Watt
Dimensions

Product
17.4 x 21.7 x 3.5 inch
Packing
22.8 x 26.9 x 7.8 inch
Weight

Net
46.2 lbs
Certifications
CE, FCC, RoHS2, Reach Compliant
